High-Performance Si PIN Photodiodes
The Ultimate BPW34S Alternatives
Upgrade your optical systems with the PDCP08 Series. Engineered for ultra-low dark current, wide spectral response, and high sensitivity. The perfect drop-in replacement for BPW34 and BPW34S.
Request Datasheet & PricingDirect Replacement
Seamless integration with identical footprint compatibility to BPW34S.
Ultra-Low Dark Current
Down to 5pA (Typ), providing superior signal-to-noise ratio for precision.
Wide Spectral Range
Broadband response from 340nm to 1100nm covering UV to Near-IR.
High Reliability
Industrial-grade quality perfect for optical switches and sensors.
Explore the PDCP08 Series
Select the perfect photodiode tailored to your specific wavelength and sensitivity requirements.
PDCP08-501
- Spectral Range 450 - 1100 nm
- Peak Wavelength 940 nm
- Dark Current (Typ) 20 pA
- Junction Capacitance 70 pF
- Window Material Epoxy resin (CR)
PDCP08-502
- Spectral Range 340 - 1100 nm
- Peak Wavelength 920 nm
- Dark Current (Typ) 5 pA
- Junction Capacitance 125 pF
- Window Material Epoxy resin (CR)
PDCP08-511
- Spectral Range 850 - 1100 nm
- Peak Wavelength 940 nm
- Dark Current (Typ) 20 pA
- Junction Capacitance 70 pF
- Window Material Epoxy resin (BK)
Technical Comparison vs BPW34S
See why engineers are switching to the PDCP08 series for lower noise and better performance.
| Parameter | BPW34S (Standard) | PDCP08-501 | PDCP08-502 | PDCP08-511 |
|---|---|---|---|---|
| Spectral Range (λ0.1) | 430 to 1100 nm | 450 to 1100 nm | 340 to 1100 nm | 850 to 1100 nm |
| Peak Sensitivity (λp) | 900 nm | 940 nm | 920 nm | 940 nm |
| Dark Current (Typ) | 2000 pA (2 nA) | 20 pA | 5 pA | 20 pA |
| Photosensitive Area | 7.5 mm² | 2.9 × 2.9 mm | 2.9 × 2.8 mm | 2.9 × 2.9 mm |
| Rise Time (Typ) | 100 ns | 150 ns | 270 ns | 150 ns |
| Package Form | Top View | Top View (2pin) | Top View (2pin) | Top View (2pin) |
Why Partner With Us?
As a leading manufacturer of optoelectronic components, we provide more than just parts—we provide reliable solutions for your supply chain.
-
Advanced Manufacturing: State-of-the-art facilities ensuring consistent quality and high yield.
-
Customization Available: Tailor photosensitive area, window material, and pin configurations to your specific needs.
-
Global Supply Chain: Fast lead times and reliable international shipping for B2B clients worldwide.
Ready to Upgrade Your Optical Sensors?
Contact our engineering sales team today to get the full datasheet, request samples, or discuss bulk pricing for your project.
Contact Sales Team
