Light source LED series E940-15-301

Our high-performance optical switch light source comes in a compact TO18 package. This light source for optical switches ensures excellent uniformity and reliability for telecom.

Category Light source Tags Fiber Optic Light Source, High Uniformity, Network Hardware Components, Optical Switch Light Source, Optocoupler LED, Resin Encapsulated, Telecom Components, TO18 2PIN Brand: Bee Photon

Product Category

Phone Support

0519-88288870

Email Support

info@photo-detector.com

Product Description

LED series
Type no.	Peak sensitivity wavelength	Forward voltage	Luminous intensity	Angle of half intensity	Window material	Package
Type no.	[nm]	[V]	[mW]	[deg]	Window material	Package
E850-15-301	850	1.5	15	100	Resin	TO18/2PIN
E850-15-202	850	1.5	15	10	Ball lens	TO18/2PIN
E940-15-301	940	1.2	15	100	Resin	TO18/2PIN
E850-30-101	850	1.4	30	20	Resin	3mm Plastic/DIP
E660-10-001	650	2	10	120	Resin	Plastic/SMD
